钴
高 钢 铣 刀 系 列
|
|
| |
Series
No.118102
|
| |
|
|
|
| |
|
ROUGHING
END MILLS
Short Length, Multi-Flute, Coarse Pitch, Round
Profile, with Flatted Shank
品名：粗加工钴高钢铣刀
描述：短柄，多刃，粗纹，圆齿形，平柄。
|
|
Mill
Dia.
e8(d1)
铣 径
|
Shank
Dia.
h6(d2)
柄 径
|
Flute
Length
l2
刃 长
|
Overall
Length
l1
总 长
|
No.
of
Flute
刃数
|
HSS
Co8
|
TiAlN
HSS Co8
TiAlN涂层
|
TiCN
HSS Co8
TiCN涂层
|
|
6.0
|
6.0
|
13.0
|
57.0
|
3
|
1181020600
|
1181210600
|
1181070600
|
|
7.0
|
10.0
|
16.0
|
66.0
|
3
|
1181020700
|
1181210700
|
1181070700
|
|
8.0
|
19.0
|
69.0
|
3
|
1181020800
|
1181210800
|
1181070800
|
|
9.0
|
19.0
|
3
|
1181020900
|
1181210900
|
1181070900
|
|
10.0
|
22.0
|
72.0
|
4
|
1181021000
|
1181211000
|
1181071000
|
|
11.0
|
12.0
|
22.0
|
79.0
|
4
|
1181021100
|
1181211100
|
1181071100
|
|
12.0
|
26.0
|
83.0
|
4
|
1181021200
|
1181211200
|
1181071200
|
|
13.0
|
26.0
|
4
|
1181021300
|
1181211300
|
1181071300
|
|
14.0
|
26.0
|
4
|
1181021400
|
1181211400
|
1181071400
|
|
15.0
|
26.0
|
4
|
1181021500
|
1181211500
|
1181071500
|
|
16.0
|
16.0
|
32.0
|
92.0
|
4
|
1181021600
|
1181211600
|
1181071600
|
|
17.0
|
32.0
|
4
|
1181021700
|
1181211700
|
1181071700
|
|
18.0
|
32.0
|
4
|
1181021800
|
1181211800
|
1181071800
|
|
19.0
|
32.0
|
4
|
1181021900
|
1181211900
|
1181071900
|
|
20.0
|
38.0
|
98.0
|
4
|
1181029001
|
1181219001
|
1181079001
|
|
20.0
|
20.0
|
38.0
|
104.0
|
4
|
1181022000
|
1181212000
|
1181072000
|
|
22.0
|
38.0
|
5
|
1181022200
|
1181212200
|
1181072200
|
|
22.0
|
25.0
|
38.0
|
114.0
|
5
|
1181029002
|
1181219002
|
1181079002
|
|
24.0
|
45.0
|
121.0
|
5
|
1181022400
|
1181212400
|
1181072400
|
|
25.0
|
45.0
|
5
|
1181022500
|
1181212500
|
1181072500
|
|
26.0
|
45.0
|
6
|
1181022600
|
1181212600
|
1181072600
|
|
28.0
|
45.0
|
6
|
1181022800
|
1181212800
|
1181072800
|
|
30.0
|
45.0
|
6
|
1181023000
|
1181213000
|
1181073000
|
|
32.0
|
32.0
|
53.0
|
133.0
|
6
|
1181023200
|
1181213200
|
1181073200
|
|
35.0
|
53.0
|
6
|
1181023500
|
1181213500
|
1181073500
|
|
36.0
|
53.0
|
6
|
1181023600
|
1181213600
|
1181073600
|
|
38.0
|
63.0
|
155.0
|
6
|
1181023800
|
1181213800
|
1181073800
|
|
38.0
|
40.0
|
63.0
|
6
|
1181029003
|
1181219003
|
1181079003
|
|
40.0
|
32.0
|
63.0
|
6
|
1181024000
|
1181214000
|
1181074000
|
|
40.0
|
40.0
|
63.0
|
6
|
1181029004
|
1181219004
|
1181079004
|
|
50.0
|
50.0
|
75.0
|
177.0
|
6
|
1181025000
|
1181215000
|
1181075000
|
|
|
|
|
|
|
|
|
|
| |
| |
|
Tolerances
according to DIN 7160 & 7161
尺 寸 公 差
|
|
|
1- 3
|
3-6
|
6-10
|
10-18
|
18-30
|
30-50
|
|
js12
|
±50
|
±60
|
±75
|
±90
|
±105
|
±125
|
|
h6
|
0
- 6
|
0
-
8
|
0
- 9
|
0
- 11
|
0
-13
|
0
-16
|
|
|
|
|
|
|
|
|
|
|
|
|
|
